Product Brand

Turbochef

PRODUCT MODEL No

i3

Product Serial Number

Spare Parts Drawing
sptc.i3_a4_drawing1_spare_parts sptc.i3_a4_drawing2_spare_parts sptc.i3_a5_drawing3_spare_parts sptc.i3_a4_drawing4_spare_parts sptc.i3_a4_drawing5_spare_parts sptc.i3_a4_drawing6_spare_parts
If the part you are looking for does not appear on the list below, it is not currently available in stock to purchase. Please contact the Stoddart Service & Spares Team to enquire about availability and lead times here.

Spare Parts

    Finger Guard Fan
    SPAR.TCO.100086
    $32.81
      Bracket, Capacitor
      SPAR.TCO.100134
      $37.75
        High Voltage Diode
        SPAR.TCO.100481
        $85.45
          Dual Capacitor 0.91uF+0.19uF 2500VAC
          SPAR.TCO.100232
          $228.07
            Fuse, Amp 12, ATMR - individual fuse
            SPAR.TCO.100592
            $101.36
              Fuse, Amp 20, ATMR - individual fuse
              SPAR.TCO.100599
              $96.93
                20A Relay 24VDC SP
                SPAR.TCO.101274
                $65.22
                  3 Pole Double Throw Relay K6
                  SPAR.TCO.101272
                  $165.61
                    2 Pole Relay
                    SPAR.TCO.101273
                    $171.81
                      30A 3 Pole Fuse Block
                      SPAR.TCO.103566
                      $249.10
                        Service Kit - Smart Card Reader
                        SPAR.TCO.CON-3020
                        $1,904.58
                          Stirrer Motor Gear -15 RPM 230V
                          SPAR.TCO.105108
                          $1,137.76
                            Aspen Dual Axis Controller Motor (BMSC)
                            SPAR.TCO.CON-7039
                            $4,257.35
                              Switch Interlock
                              SPAR.TCO.102012
                              $25.51
                                Klixon Magnetron Thermostat
                                SPAR.TCO.102070
                                $72.52
                                  EGO High Limit Thermostat 300C
                                  SPAR.TCO.102075
                                  $523.89
                                    Snap Disk Thermostat N/O Close on Rise 120F
                                    SPAR.TCO.102086
                                    $33.90
                                      Service Kit - Cooling Fan with Self Tap Screws
                                      SPAR.TCO.HHB-3234
                                      $284.73
                                        Black Membrane Switch Keypad
                                        SPAR.TCO.I3-9247
                                        $585.43
                                          Mag Fan with Capacitor Service Kit to suit i3
                                          SPAR.TCO.I3-3201
                                          $1,860.76
                                            Complete Door Service Kit to suit i3
                                            SPAR.TCO.I3-3211
                                            $3,052.98
                                              4.75" Long Gortex Tape Service Kit
                                              SPAR.TCO.I3-3216
                                              $149.12
                                                Dual Window Jetplate Service Kit to suit i3
                                                SPAR.TCO.I3-3218
                                                $1,882.11
                                                  Stirrer Shaft Assembly Service Kit
                                                  SPAR.TCO.I3-3227
                                                  $1,467.39
                                                    Catalytic Converter
                                                    SPAR.TCO.I3-9066
                                                    $3,408.51
                                                      Torsion Bar Hinge Assembly
                                                      SPAR.TCO.I3-9144
                                                      $1,676.09
                                                        Lower Front Cover
                                                        SPAR.TCO.I3-9246
                                                        $612.90
                                                          Left Side Cover
                                                          SPAR.TCO.I3-9301.B
                                                          $741.10
                                                            3000W Helical Heater Element 208v
                                                            SPAR.TCO.I3-9378
                                                            $488.55
                                                              Standard Top Jetplate
                                                              SPAR.TCO.I5-3204
                                                              $2,548.91
                                                                Display (TFT) Service Kit to suit i5
                                                                SPAR.TCO.I5-3207
                                                                $2,435.56
                                                                  Waveguide Service Kit to suit i3 and i5
                                                                  SPAR.TCO.I5-3210
                                                                  $1,705.01
                                                                    Stirrer Shaft Assembly Service Kit
                                                                    SPAR.TCO.I5-3217
                                                                    $694.21
                                                                      Top Blower Motor Service Kit to suit i5
                                                                      SPAR.TCO.I5-3218-3
                                                                      $3,359.78
                                                                        Bottom Blower Motor Service Kit to suit i5
                                                                        SPAR.TCO.I5-3218-4
                                                                        $3,359.78
                                                                          Stirrer Blade Assembly
                                                                          SPAR.TCO.I5-9154
                                                                          $805.97
                                                                            Hand hold Plug
                                                                            SPAR.TCO.I5-9256
                                                                            $36.49
                                                                              Waveguide Gasket
                                                                              SPAR.TCO.I5-9331
                                                                              $359.43
                                                                                Magneton Service Kit
                                                                                SPAR.TCO.NGC-3015
                                                                                $479.81
                                                                                  50Hz HV Transformer with packaging Kit
                                                                                  SPAR.TCO.NGC-3062-2
                                                                                  $1,296.94
                                                                                    24 VDC Power Supply and Bracket Service Kit
                                                                                    SPAR.TCO.NGC-3069
                                                                                    $619.68
                                                                                      Foil Pack
                                                                                      SPAR.TCO.RWD-9191
                                                                                      $564.97
                                                                                        Cooling Fan with Connector 230v
                                                                                        SPAR.TCO.TC3-0433
                                                                                        $711.85
                                                                                          Aluminium Bottom Guide Block
                                                                                          SPAR.TCO.I5-9393
                                                                                          $95.56
                                                                                            Aluminium Upper Guide Block
                                                                                            SPAR.TCO.I5-9394
                                                                                            $115.10
                                                                                              Counterbalance Bracket Weldment
                                                                                              SPAR.TCO.I5-9326
                                                                                              $359.31
                                                                                                Door Gasket
                                                                                                SPAR.TCO.I3-9309
                                                                                                $230.89
                                                                                                  Left Hand Side Hinge Cam Weldment
                                                                                                  SPAR.TCO.I5-9313
                                                                                                  $1,544.49
                                                                                                    Right Hand Side Hinge Cam Weldment
                                                                                                    SPAR.TCO.I5-9314
                                                                                                    $1,411.17
                                                                                                      Left Hand Gusset Hing to suit i5
                                                                                                      SPAR.TCO.I5-9178
                                                                                                      $211.41
                                                                                                        Right Hand Gusset Hing to suit i5
                                                                                                        SPAR.TCO.I5-9179
                                                                                                        $211

                                                                                                        Consumables
