Product Brand

Woodson

PRODUCT MODEL No

W.CVT.BUN.30

Product Serial Number

Spare Parts Drawing
w.cvt.bun.30_a2_spare_parts
If the part you are looking for does not appear on the list below, it is not currently available in stock to purchase. Please contact the Stoddart Service & Spares Team to enquire about availability and lead times here.

Spare Parts

    5.5kw Contactor
    CMEL.0093
    $59.08
      Axial Compact Fan 240V 120 x 120 x 38mm
      CMEL.1965
      $131.77
        Transformer 230V 12V 50VA
        CMEL.1975
        $170.83
          Rotary encoder 5 24VDC
          CMEL.2159
          $440.36
            Solid State Relay 40Amp 5 24VDC
            CMEL.2161
            $224.76
              Drive 48OD 25/64 ID 1.57
              CMGE.2070
              $99.51
                Sprocket 16 Teeth 3/8" Pitch 8mm Bore
                CMGE.2040
                $22.54
                  Chain Drive
                  CMGE.2047
                  $12.26
                    Links for chain
                    CMGE.2048
                    $4
                      Conveyor Belt Flat Flex 450mm wide
                      CMGE.2058
                      $364
                        Gear head gear ratio 60
                        CMMG.0004
                        $262.36
                          Motor dc 15w 12v 3200rpm s6d15-12a
                          CMMG.0006
                          $272.16
                            Gear head inter decimal 6mm shaft 10b
                            CMMG.0008
                            $272.16
                              Heat Sink KHS 120 Series
                              CMEL.2160
                              $33.94
